Dimensions
Article Diameter (in mm) 1320
Article Height (in mm) 295
Canopy Height (in mm) 50
Canopy Diameter (in mm) 170
Net Weight 6.8 Kilogram
Gross Weight 8 Kilogram
Single-Box Height (in mm) 251
Single-Box Length (in mm) 768
Single-Box Depth (in mm) 427
Fan
Motor Type DC
Motor dimension in MM (Ø x H) 155x12
Motor Wattage 24
Adjustable Canopy 13°
Blade pitch in degree 16°
Blade Quantity 3
Mains Voltage 220-240V, 50Hz
Performance
Wattage by air movement (1) 3
RPM (1) 60
Air Movement m3/Hr (1) 3243
Wattage by air movement (2) 6
RPM (2) 101
Air Movement m3/Hr (2) 5794
Wattage by air movement (3) 7
RPM (3) 121
Air Movement m3/Hr (3) 7420
Wattage by air movement (4) 11
RPM (4) 141
Air Movement m3/Hr (4) 9262
Wattage by air movement (5) 16
RPM (5) 160
Air Movement m3/Hr (5) 10847
Wattage by air movement (6) 25
RPM (6) 190
Air Movement m3/Hr (6) 13280
