Dimensions Article Diameter (in mm) 1524 Article Height (in mm) 413 Canopy Height (in mm) 54 Canopy Diameter (in mm) 150 Net Weight 12.8 Kilogram Gross Weight 14.3 Kilogram Single-Box Height (in mm) 259 Single-Box Length (in mm) 980 Single-Box Depth (in mm) 402
Fan Motor Type DC Motor dimension in MM (Ø x H) 180x17 Motor Wattage 47 Blade pitch in degree 18° Blade Quantity 7 Mains Voltage 220-240V, 50Hz
Functions Function remote control incl. timer reversible 5 speeds
Material & Colour Blade Material aluminium Canopy Material steel Enclosure Material steel
Performance Wattage by air movement (1) 6.3 RPM (1) 63 Air Movement m3/Hr (1) 5270 Wattage by air movement (2) 11 RPM (2) 82 Air Movement m3/Hr (2) 6630 Wattage by air movement (3) 19.2 RPM (3) 105 Air Movement m3/Hr (3) 7650 Wattage by air movement (4) 30 RPM (4) 122 Air Movement m3/Hr (4) 9520 Wattage by air movement (5) 47 RPM (5) 143 Air Movement m3/Hr (5) 10700
