Name: 12v 30w Waterproof IP67 LED Driver LED Power Supply
Brand: Qzao
SKU: 11622
Availability: InStock

12v 30w Waterproof IP67 LED Driver LED Power Supply

SKU

11622

Product variants

$39.00

$39.00 ~~$49.00~~

Sale

Sold Out

Tax included. Shipping calculated at checkout.

Quantity

Model		VUO-030-012A1
Output	DC voltage	12V
	Rated current	2.5A
	Current range	0~2.5A
	rated power	30W
	Ripple & Noise (peak to peak)	<240mV
	No-load voltage	±0.5V
Input	voltage range	90~265VAC
	Current	47~63Hz
	Power factor	no PFC
	effectiveness(Typ.)	82%
	Alternating current(Typ.)	0.22A/220VAC
Protection	Short circuit	Protection mode: hiccup mode, abnormal conditions can be automatically restored after removal
	overload	3.9A
environment	Operating temperature	-30~+50℃ (Please refer to the load reduction curve)
	Protection class	IP67 Suitable for indoor and outdoor use
	Storage temperature	-40~+80℃
Safety&EMC	Safety standards	Suitable for EN61347-1;EN61347-2-13;SELV;IP67
	Pressure	Input - Output: 2KVAC Input - Enclosure, Ground: 2KVAC Output - Enclosure, Ground: 0.5KVAC
	Dimming method	Triple (0 / 1-10Vdc or 10V PWM or resistor)

Tips	1.If without specia explanation, all specifications are measured at an input of 220VAC, rated load, ambient temperature of 25 ° C . 2.Ripple & Noise Measurement Method: Use a 12 '' twisted pair, and the terminals are connected in parallel with 0.1uF and 47uF capacitors and tested at 20MHz bandwidth.
